James Burn DCR-400 Dual Corner Rounding Machine

The DCR-400 is a compact machine designed to make round corners on any material ranging from books, note pads, diaries, cards. Right and left corners can be cut simultaneously in a single stroke. The cutting thickness of up to 100mm combined with a mechanical speed of up to 24 cycles / minute provide optimum output for a one man operation. It is the ideal solution for medium to long runs with a regular output.

Features:

* Productivity : the right and left corners can be cut simultaneously in a single stroke. The cutting thickness of up to 100mm combined with a speed of up to 24 cycles / minute provide optimum output for a one man operation.

* Versatile : The DCR-400 can accommodate a wide range of dies with radius ranging from 1/8″ to 1″. It can also be operated as a single corner rounding machine.

* User-friendly : easy adjustments and adjustable work table angle ensure optimum working conditions.

Specifications:

• Feeding Mode: Manual

• Max Paper Sizes: 400 x 297 mm

• Min Paper Sizes: 88 x 55 mm

• Speed: 24 cycles/minute

• Max Cutting Thickness (paper only): 100 mm

• Die Radius from: 1/8″ to 1″

• Work Table Adjustable Angle: Up to 20°

• Voltage: 200/240 V (50 Hz) 1 ph – 110/120 V (60 Hz) 1 ph

• Power Consumption: 0.25 kW

• Air Pressure: 6 to 8 bars

• Dimensions: 0.84 x 0.83 x 1.31 (H/a) m

• Net Weight: 220 kg
